Ubiquiti 5GHz PtMP LTU Long-Range Client Radio LTU-LR

Incorporating innovative industrial design with advanced technology, the LTU-LR is an outdoor PtMP 5 GHz Radio with an integrated antenna designed for use as a PtMP CPE. LTU technology that breaks through the limitations of 802.11 Wi-Fi technology and supports 1024QAM for high performance and flexible bandwidth (10/20/30/40/50 MHz).

Based on Ubiquiti’s LTU technology, the LTU LR is not impeded by the limitations of standard 802.11 WiFi technology. Its custom LTU silicon and radio architecture provide up to 600+ Mbps of real TCP/IP throughput and modulation rates of up to 4096QAM.

The LTU LR supports both bridged and built-in hardware NAT router modes to suit your specific deployment. It can also use different frequencies for TX and RX to avoid interference.

The LTU LR directs RF energy in a tighter beamwidth. With the focus in one direction, the LTU LR blocks or spatially filters out noise to improve noise immunity. This is especially important in an area crowded with other RF signals of the same or similar frequency.

Ubiquiti’s InnerFeed technology integrates the radio into the feedhorn of a 26 dBi antenna, so there is no need for a cable. This improves performance because it eliminates cable losses.

Ubiquiti LTU-LR Key Highlights

• PtMP CPE
• 1024 QAM
• 10/20/30/40/50 MHz channel bandwidth
• Central configuration management from AP side
• Frequency split
• Auto power adjustments
• Router mode support
• Range up to 30km
• Functions in a PtMP environment with the as the basestation

What’s in the Box?

• 1 x antenna feed
• 1 x center reflector panel
• 2 x side reflector panels
• 1 x mounting bracket
• 1 x rear housing
• 2 x pivot panels
• 8 x M4 SEM screws
• 4 x M8 SEM screws
• 3 x metal straps
• Gigabit PoE (24V, 0.5A) with Mounting Bracket
• UK power cord
• Quick Start Guide
